VS836 25HP High Operating Efficiency Ride On Concrete Troweling Machine Ride On Power Trowel Driving Type Power Trowel Machine
（1）Driving operation greatly reduces labor intensity compared with hand-held operation.
（2）The double disc work greatly improves the work efficiency. It can install two pulping discs at the same time to carry out rapid pulping. The construction efficiency is 5-8 times higher than that of the ordinary trowel, and the single operation reduces the labor cost.
（3）The weight is heavier, the compaction effect is better to the ground, the density of the concrete ground is greatly improved, and the construction efficiency is higher than that of the handheld trowel machine.
（4）Mechanical steering operation, stable and reliable, responsive, comfortable operation.
（5）Equipped with Honda GX690 high horsepower electric start engine, the power is strong and reliable.
（6）Equipped with reinforced gearbox, it has large torque and stable quality.
（7）The pedal safety switch can quickly shut down the engine and provide greater security.
（8）The pedal throttle control is sensitive and fast.
（9）Equipped with 19L water tank and fuel tank, it can work continuously for a long time.
（10）Copper sprinkler joint and valve can effectively prevent rust of sprinkler system.
（11）High brightness lamp can work in dark environment.
Send Inquiry
Product Details ofVS836 25HP High Operating Efficiency Ride On Concrete Troweling Machine Ride On Power Trowel Driving Type Power Trowel Machine
Product characteristics
★ Driving operation greatly reduces labor intensity and improves work efficiency. The construction efficiency is 5-8 times that of ordinary trowel machines. Single-person operation reduces construction costs.
★ Double discs work, heavier weight, better compaction effect on the ground, greatly improving the density of the road surface. The construction efficiency is higher than that of a walk-behind trowel machine.
★ Two slurry discs can be installed at the same time for rapid slurry lifting.
★ Mechanical steering operation system, sensitive response, easy control, flexible and comfortable operation.
★ Equipped with a world-renowned brand Honda gasoline high-horsepower electric start engine, providing strong and reliable power.
★ Foot-operated safety cut-off switch, which can quickly shut down the engine and provide maximum safety protection.
★ Foot-operated throttle control, sensitive response, fast speed increase.
★ Low center of gravity design, so that the whole machine has good working performance.
★ Equipped with a large capacity water tank.
★ Water spray and lighting devices are more helpful for construction.
★ Used for slurry lifting, leveling and polishing of cement concrete surfaces. Widely used in the construction of cement concrete pavements and floors such as high standard highways, warehouses, and sites.
★ Optional walking device makes it more convenient to move on the construction site.
Products show
Products details
Mechanical steering operation, stable and reliable, responsive, comfortable operation.
Equipped with reinforced gearbox, it has large torque and stable quality.
Featuring a high-horsepower electric start engine from Honda GX690, this equipment boasts robust and dependable power.
A luminous light fixture is capable of functioning effectively in low-light settings.
The foot-actuated safety mechanism allows for immediate engine cessation, enhancing overall security. Additionally, the foot throttle control offers responsive and swift operation.
Furnished with a 19-liter capacity for both water and fuel, the device ensures extended periods of uninterrupted operation.
Products Parameter
|
VS836 |
|
HONDA GX690 |
|
Higher than 90# gasoline |
|
19L |
|
96cm*2/ 36inch*2 |
|
19L |
|
350(L)*150(W)mm/ 13.78*5.9inch |
|
25HP/ 18.4kW |
|
2000*1000*1300mm/ 6.56*3.28*4.27ft |
|
Mechanical drive |
|
380kgs / 838lbs |
|
80-150RPM |
application & partner
company information
instruction
Established in 2013, the Shandong Vanse Group seized the moment presented by the booming concrete sector and focused on premium, high-quality, and efficient solutions. Rapidly evolving into a national high-tech firm, it specializes in the R&D, production, sales, and after-sales service of concrete machinery. Notable partnerships include collaborations with entities like Jingdong Logistics, Ningde Times, Great Wall Motors, and the China State Construction Engineering Corporation (CSCEC).
The corporate structure of Vanse Group includes divisions such as Vanse Machinery, Wanhui New Energy, Wanli Precast Machinery Manufacturing, Vanse Road & Bridge, and Shanghai Vanse Machinery. Their market reach spans all of China's provinces, municipalities, and autonomous regions, and their products are exported to over 30 nations including the United States, United Kingdom, Russia, Germany, Saudi Arabia, and Australia.
In 2018, Vanse entered into a technological collaboration with UK specialists, incorporating advanced international techniques to meet global standards in ergonomic design and performance paired with laser systems. Additionally, Vanse forged strong ties with educational institutions like Shandong University and Chang'an University, blending industry, academic research, and practical applications.
Continuously contemplating the future, Vanse Group strives to contribute to a better quality of life for humanity.
Embracing today and envisioning tomorrow, Vanse Group is committed to crafting a luminous future alongside its partners.
