VANSE YZS2-4 Industrial Concrete Floor Machine Concrete Leveling Machine
✅ Four wheel drive, equipped with anti-slip system, can meet complex work conditions.
✅ Suspended wheels can achieve extremely high passability.
✅ Max. 90° transverse walk, more agile and easy to operate.
✅ Soft landing function.
✅ Quick disasembled leveling head.
✅ Standard configurated with seat, luggage compartment and high-pressure cleaner.
✅ Unique design of the protective cover can maximize the protection of the walking motor.
✅ Engine designed with an under-exhaust system, the upper part of the engine compartment is completely sealed, enhances the waterproof performance.
Send Inquiry
Product Details ofVANSE YZS2-4 Industrial Concrete Floor Machine Concrete Leveling Machine
How to Maximize Flooring Precision with a Concrete Laser Leveling Machine in USA?
Pain Points: In the competitive US construction market, contractors face rising labor costs and strict adherence to ASTM E1155 standards for F-numbers (Floor Flatness/Levelness). Traditional screeding methods often fail to meet these high-tolerance requirements efficiently, leading to costly rework and project delays.
Solution: The YZS2-4 remote control boom type concrete laser leveling machine is engineered to solve these specific challenges. By integrating advanced laser technology with a telescopic boom, this machine ensures superior flatness while significantly reducing manual labor. It allows US contractors to achieve superflat floors in large-scale warehouses and commercial projects with ease.
Key Features:
Intelligent Operation: The remote control system provides the operator with a clear view of the site, ensuring safety and precision.
High Efficiency: Equipped with a powerful engine, this concrete laser leveling machine covers large areas quickly, reducing project timelines.
Environmental Compliance: Our models are designed with EPA approved engines to meet strict US environmental emission regulations.
Versatility: The telescopic boom allows the machine to reach over obstacles and rebar, making it ideal for complex slab-on-grade projects.
FEATURES
Master Tight Spaces
Engineered with Multi-Mode Steering (including 2-wheel, 4-wheel, and Crab steering), this machine navigates confined workspaces and obstacles with ease, making it ideal for crowded warehouse interiors.
Precision Control
The Telescopic Leveling Head with a 6-meter boom allows you to reach over rebar and messy subgrades, delivering a superior floor finish without disturbing the reinforcement.
Rough Terrain Ready
Featuring Four-Wheel Drive (4WD) and a High Ground Clearance chassis, the YZS2-4 handles uneven or soft subgrades effortlessly while maintaining stability via its Suspended Wheels system.
Remote Operation
Enhance job site safety and visibility with full remote control capabilities, giving operators a better vantage point for precision work.
SPECIFICATIONS
| Engine model | YANMAR 3TNV80F | Fuel tank capacity | 70L |
| Power | 17.8kW/3000RPM | Steering mode | Two wheel, four wheel, crab steering |
| Fuel | Diesel | Exciting force | 200-900N(MAX) |
| Leveling width | 3m/9.84ft | Telescopic boom | 5.5m/18ft long |
| Walking speed | 4.5kM/H | Net weight | 2340kgs/5159lbs |
| Dimension | 4600×3430×1970mm/15.09×11.25×6.46ft | ||
| Transportation size | Machine body:4400×1880×1970mm /14.44×6.17×6.46ft | ||
| Working head:3430×815×530mm /11.25×2.67×1.74ft | |||
FAQ
Q1/
Does this machine meet US emission standards?
A1/
Yes, the YZS2-4 can be equipped with an EPA approved engine, ensuring compliance with US environmental laws.
Q2/
Do you provide after-sales support in the USA?
A2/
Absolutely. We support one-stop service, including technical guidance, parts supply, and troubleshooting to keep your project running.
Q3/
Is this a concrete laser leveling machine with stand laser level machine compatibility?
A3/
Yes, the YZS2-4 works seamlessly as a concrete laser leveling machine with stand laser level machine integration, ensuring the reference plane is maintained perfectly across the site.
CTA: Ready to upgrade your fleet? Contact us today for a quote on the YZS2-4 and see how we can streamline your next US flooring project.
