The official maintenance guide and recommended cycle for the power trowel machine

The power trowel (concrete power trowel) is a heavy-duty construction equipment, and its performance and service life are highly dependent on regular and correct maintenance. The following is a comprehensive official maintenance guide and recommended cycle, applicable to common fuel (gasoline/diesel) -driven power trowels.

Core principle

Safety first: Before any maintenance, make sure the machine is completely shut down, the engine is off, and the blades/power trowels have completely stopped.

Use genuine accessories: Always use the engine oil, lubricating oil, air filter, spark plugs and other accessories recommended by the manufacturer.

Record maintenance logs: Detail the date, items and usage hours of each maintenance.

Daily maintenance (before and after each use)

Cleanliness (most important)

Immediately after use: Remove all concrete slurry, dirt and debris from the power trowel, blades, chassis and all parts of the machine. The remaining concrete will harden, causing imbalance and damage to the machine.

Clean the body: Wipe the body with a damp cloth to prevent dust from clogging the heat sink and air filter.

Check the fasteners

Check and tighten all bolts and nuts, especially the blade fixing bolts, the power trowel plate connecting parts and the engine base bolts. Vibration can easily cause it to loosen.

Check the blade/power trowel:

Check the wear condition to ensure that its edges are flat and free from severe wear or cracks. Change or adjust the Angle as needed.

Fuel system (only for the last use of the day) :

Fuel tank: If the machine will be idle for more than 30 days, it is recommended to empty the fuel in the fuel tank and carburetor, or add fuel stabilizer to prevent clogging of the fuel lines and carburetor.

Regular maintenance (based on operating hours

Maintain every 8 to 25 hours of operation or weekly

Air filter

In environments with extremely high levels of dust (such as concrete construction), it may be necessary to clean after each use.

Remove the paper filter element and gently tap it to remove the dust. If there is compressed air, blow it clean from the inside out (the air pressure should not be too high). Check if the filter element is damaged. If it is, it must be replaced.

Check and clean the sponge pre-filter element (if any).

Engine oil inspection (for four-stroke engines)

On a level ground, check the engine oil level with an oil dipstick. Add engine oil of the specified grade (SAE 10W-30 or as per the instructions) as needed.

Transmission gearbox

Check the lubricating oil level of the gearbox (if there is an observation window or dipstick), and add the specified gear oil if necessary.

Maintenance is required every 50 hours of operation or monthly

Change the engine oil (for four-stroke engines) : The first change should be made 25 hours after the first use, and then every 50 hours thereafter. When warming up the machine, drain the old oil and add new engine oil to the specified amount.

Thoroughly clean the air filter and consider replacing it: Even if cleaned frequently, the paper filter element has a lifespan and should be replaced regularly.

Check/clean the spark plugs: Remove carbon deposits, check the electrode gap, and adjust it to the value specified in the manual (usually 0.6-0.8mm).

Lubrication

Use a grease gun to apply high-quality lithium-based grease to all oiling nozzles (steering bearings, lifting screws, connecting rods, etc.).

Check the movable joint areas and apply lubricating oil manually to prevent rust.

Inspect the drive belt/V-belt: Check for cracks, wear or looseness, and adjust the tension as required by the manual or replace it.

Maintenance is required every 100 hours of operation or every quarter

Replace the air filter element: Regardless of its appearance, it is recommended to replace it regularly.
Replace the fuel filter: Clean the fuel system and replace the fuel filter screen or filter.
Check/adjust idle speed and throttle line: Ensure stable engine idle speed and flexible operation.
Thoroughly inspect the gearbox oil: If there is turbidity or metal shavings, consider replacing the gear oil.

Maintenance should be carried out every 300 hours of operation or annually/before long-term storage

Comprehensive major maintenance: It is recommended to send it to an authorized service center for handling.
Deep cleaning: Thoroughly clean the entire machine.
Replace all filters: air, fuel and oil filters (if any).
Replace spark plugs: Replace with new spark plugs of the specified model.
Inspect/Replace carbon brushes (for motorized power trowels) : For electric power trowels, check the wear of the motor carbon brushes and replace them in a timely manner.
Fuel system completely drained

Drain all the fuel from the fuel tank and carburetor.
Or fill up the tank with fuel and add fuel stabilizer, and run the engine for a few minutes to allow the stabilizer to circulate to the carburetor.
Battery maintenance (electric start model)

Disconnect the negative terminal of the battery.
Charge the battery and maintain it regularly (charge it once every 1-2 months).
Storage location: Store the machine in a clean, dry and well-ventilated room and cover it with a cover.

Seasonal/long-term storage maintenance

If the equipment is idle for more than one month during the non-construction season, the following steps must be carried out
Fuel treatment: As mentioned above, drain or add stabilizer.
Engine protection

Inject a small amount of engine oil into the spark plug hole, pull the starting rope several times to lubricate the cylinder with the engine oil, and then install the spark plug.
Place the engine at the top dead center of compression (stop when you feel resistance when pulling the start rope).
Rust prevention treatment: Apply rust prevention oil to all exposed metal parts.
Lift the power trowel: Use a wooden board to prop up the power trowel and lift it off the ground to reduce the pressure on the tires and suspension.

Safety and Operation Check (Before each startup)

Oil and water inspection: Engine oil, fuel oil.
Visual inspection: Check for any oil leakage or damaged components.
Operation test: Start the machine under no-load conditions in a safe area to check if the steering and lifting are flexible and if there are any abnormal noises.
Protective devices: Ensure that all protective covers (belts, gears) are in good condition and firmly installed.
Final reminder: This guide is general advice. For the most accurate maintenance requirements, please be sure to refer to the "User Operation and Maintenance Manual" of the polishing model you have purchased. Adhering to the cycles and norms specified in the official manual for maintenance is the key to ensuring the performance, safety and service life of the equipment.



Note: The parameters provided in this document are for reference only and are not mandatory. Due to differences in technical characteristics between different brands and models of laser levelers, please consult the manufacturer for a suitable solution before actual operation. This reference document assumes no responsibility for any issues arising from failure to follow the manufacturer's instructions.
