VANSE BG125 Fast Delivery Concrete Pipe Puller Machine Near Me Sale
2. The machine supports remote control operation, enabling forward, backward, turning, clamping, and lifting functions. It features three steering modes (front wheel, crab-like, and four-wheel).
3. Equipped with a Honda GX390 gasoline engine, it boasts a power output of 8.7 kW, providing strong power and low fuel consumption.
4. The hydraulic system drives the walking and clamping devices, ensuring smooth operation, low energy consumption, and a long service life, offering excellent economy and practicality.
5. The equipment is lightweight (550 kg) and equipped with pneumatic tires, allowing for flexible movement with a minimum turning radius of only 1100 mm.
6. Key components such as bearings and cylinders utilize high-quality standard parts, with a rationally designed lubrication point system requiring grease injection every 82 hours, simplifying maintenance.
Send Inquiry
Product Details ofVANSE BG125 Fast Delivery Concrete Pipe Puller Machine Near Me Sale
Products Description
The BG125 pipe puller machine is a high-efficiency, intelligent auxiliary equipment for concrete pumping. It adopts a human-like pipe-gripping structure, equipped with a hydraulic clamping device and fully remote control operation, allowing for flexible and convenient gripping of concrete hoses, and smooth and stable movement and steering.
The equipment is powered by a Honda GX390 gasoline engine with a power output of 8.7kW. It features a hydraulic drive system, achieving speeds of 0–5 km/h and a minimum turning radius of only 1100mm. With a 0.4-meter hose opening, it can accommodate various pipe diameters, easily achieving the gripping, lifting, and movement of hoses.
The BG125 pipe puller machine is widely applicable to concrete pouring scenarios such as factories, bridges, highways, and high-rise buildings, significantly reducing manual handling intensity and improving pumping efficiency. The machine has a compact structure, weighs only 550kg, and is easy to move, making it an ideal auxiliary equipment for modern construction.
Specifications
| Engine Type | Model | HONDA GX390 |
| Type | Gasoline, Air-cooled, 4-Stroke, Single-Cylinder | |
| Power | 8.7kW | |
| Lubricant Quantity (L) | 1.1 | |
| Fuel Tank Capacity (L) | 6.5 | |
| Pipe Puller | Pipe Management | Hydraulic Tightening |
| Clamp opening (m) | 0.4 | |
| Moving System | Drive Mode | Hydraulic Motor |
| Tyre Mode | Pneumatic Tyre | |
| Velocity (Km/h) | 0-5Km/h | |
| Minimum turning Radius (mm) | 1100 (With Illustration) | |
| Mode of Operation | Forward, Backward | Remote Control |
| Turn | Remote Control | |
| Fastening Motion | Remote Control | |
| Promote | Remote Control | |
| Size and Weight | Outline Dimension | 1840×1390×1000 (With Illustration) |
| Packing Measurement | 2000×1500×1100 | |
| Weight(Kg) | 550 |
