VANSE WS3-14 Kerbstone Slipform Making Machine Factory Manufacturer

Equipped with an industrial-grade wireless remote control, it supports remote operation of core functions such as walking, steering, and lifting, freeing the operator from the constraints of the operating table, and is suitable for precise operations in narrow sites or high-risk working conditions. The operator can adjust the equipment posture in real time within a range of 50 meters, reducing the time spent on going back and forth to the control console and improving construction flexibility.

The operation panel adopts a waterproof and dustproof design (IP65 protection level), the button layout follows ergonomics, and the functional divisions are clearly visible. Integrated electronic proportional control technology, through the knob and lever, you can achieve precise control of parameters such as crawler speed (0-33.5m/min stepless adjustment), mold lifting (550mm stroke), screw conveyor inclination, etc., which can be mastered quickly by novices.

The front track is independently hydraulically driven to steer, with a minimum left-turn radius of only 61cm and a right-turn radius of 6.1m, which can easily complete the construction of complex paths such as U-shaped bends and roundabouts. Without the need for additional auxiliary equipment, a single operator can achieve 360° flexible steering through the steering control knob, which is suitable for multi-scenario operations such as municipal roads and bridge guardrails.

Equipped with Cummins QSB4.5 four-cylinder diesel engine (97kW/132HP), it has stable power output and intelligent load sensing technology of hydraulic system, which can automatically match the construction load and avoid power waste. Even in high-load vibration operation, it can maintain smooth control response and reduce the sense of jamming.
